Cisco SG500-28 Administration Guide

Managing MAC Address Tables
Configuring Static MAC Addresses
263 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
15
Configuring Static MAC Addresses
Static MAC addresses are assigned to a specific physical interface and VLAN on
the device. If that address is detected on another interface, it is ignored, and is not
written to the address table.
To define a static address:
STEP 1 Click MAC Address Tables > Static Addresses.
The Static Addresses page
contains the currently defined static addresses.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• VLAN ID—Select the VLAN ID for the port.
• MAC Address—Enter the interface MAC address.
• Interface—Select an interface (unit/slot, port, or LAG) for the entry.
• Status—Select how the entry is treated. The options are:
- Permanent—The system never removes this MAC address. If the static
MAC address is saved in the Startup Configuration, it is retained after
rebooting.
- Delete on reset—The static MAC address is deleted when the device is
reset.
- Delete on timeout—The MAC address is deleted when aging occurs.
- Secure—The MAC address is secure when the interface is in classic
locked mode (see Configuring Port Security).
STEP 4 Click Apply. A new entry appears in the table.

Cisco SG500-28 Specifications

General

Ports	28
Port Type	Gigabit Ethernet
Layer	Layer 3
Switching Capacity	56 Gbps
PoE Support	No
Form Factor	Rack-mountable
RAM	256 MB
Flash Memory	32 MB
Power Supply	Internal
Jumbo Frame Support	9KB
VLAN Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% non-condensing
Dimensions	17.3 x 10.2 x 1.7 in (440 x 260 x 44 mm)
MAC Address Table Size	16, 000 entries
