Cisco SG500-28 Administration Guide

Quality of Service
Managing QoS Statistics
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 508
25
- Set 1—Displays the statistics for Set 1 that contains all interfaces and
queues with a high DP (Drop Precedence).
- Set 2—Displays the statistics for Set 2 that contains all interfaces and
queues with a low DP.
• Interface—Select the ports for which statistics are displayed. The options
are:
-
Unit No —Selects the unit number.
- Port—Selects the port on the selected unit number for which statistics
are displayed.
- All Ports—Specifies that statistics are displayed for all ports.
• Queue—Select the queue for which statistics are displayed.
• Drop Precedence—Enter drop precedence that indicates the probability of
being dropped.
STEP 6 Click Apply. The Queue Statistics counter is added, and the Running Configuration
file is updated.

Cisco SG500-28 Specifications

General

Ports	28
Port Type	Gigabit Ethernet
Layer	Layer 3
Switching Capacity	56 Gbps
PoE Support	No
Form Factor	Rack-mountable
RAM	256 MB
Flash Memory	32 MB
Power Supply	Internal
Jumbo Frame Support	9KB
VLAN Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% non-condensing
Dimensions	17.3 x 10.2 x 1.7 in (440 x 260 x 44 mm)
MAC Address Table Size	16, 000 entries
