69
Viewing Attendant Console Status
The SPA500S or SPA500DS user parameters are displayed in the Attendant Console Status window.
The table identifies and describes the values in the Attendant Console Status tab.
Parameter
Description
Unit Enable
Yes indicates the unit is enabled. No indicates it is disabled.
Unit Online
Yes indicates the unit is connected. No indicates it is not
connected.
Subscribe Expires
Time in seconds when the current subscription expires. After the
subscription expires, the attendant console automatically
requests a new subscription.
Subscribe Retry
Interval
Length of time the attendant console waits to try again if the
subscription fails.
HW Version
Hardware version of the attendant console.
SW Version
Firmware (software) version of the attendant console.
Key
Name assigned to each key (1-32) on the Cisco SPA5000S or key
1-30 on the Cisco SPA500DS.
Name
Name identifying the entry.
Type
Function (for example, speed dial) that is enabled for each key on
the attendant console.
Line
Displays the extension assigned to each key on the attendant
console.
Station
Subscribe URI (uniform resource identifier) configured for each
key on the attendant console.
