Bandwidth
Link status
The Link status page (Status > Bandwidth > Links) lists all of the links currently configured on the VCS,
along with the number of calls and the bandwidth being used by each link.
The following information is displayed:
Field Description
Name The name of each link. Clicking on a link Name takes you to the configuration page for that link.
Calls The total number of calls currently traversing the link. Note that a single call may traverse more than
one link, depending on how your system is configured.
Bandwidth
used
The total bandwidth of all the calls currently traversing the link.
Pipe status
The Pipe status page (Status > Bandwidth > Pipes) lists all of the pipes currently configured on the VCS,
along with the number of calls and the bandwidth being used by each pipe.
The following information is displayed:
Field Description
Name The name of each pipe. Clicking on a pipe Name takes you to the configuration page for that pipe.
Calls The total number of calls currently traversing the pipe. Note that a single call may traverse more than
one pipe, depending on how your system is configured.
Bandwidth
used
The total bandwidth of all the calls currently traversing the pipe.
Cisco VCS Administrator Guide (X8.1.1) Page 337 of 507
Overview and status information
Bandwidth
