Cisco UCS 6248 UP User Manual

16 Expansion module
ports
232 fixed 10-Gigabit
Ethernet ports
1
Figure 3: Cisco UCS 6248 UP Switch Rear View Close-up
16 port Expansion module3System status LED and
beaconing LED/button
1
32 fixed 10-Gigabit
Ethernet ports
2
The front connector ports are in a 2x2 stacked RJ-45 jack.
Figure 4: Connector Ports and LED Closeup
Network management
port
5Beaconing LED/button1
Console port6System Status LED2
USB port7UCS cross connect port
L1
3
UCS cross connect port
L2
4
