Procedure
Step 1 Compare the shipment to the equipment list provided by your customer service representative and verify that
you have received all items, including the following:
• Grounding lug kit
• Rack-mount kit
• ESD wrist strap
• Cables with connectors
• Any optional items ordered
Step 2 Check for damage and report any discrepancies or damage to your customer service representative. Have the
following information ready:
• Invoice number of shipper (see packing slip)
• Model and serial number of the damaged unit
• Description of damage
• Effect of damage on the installation
Installing the Cisco UCS 6248 UP Chassis in a Cabinet or Rack
This procedure describes how to use the rack-mount kit provided with the chassis to install Cisco UCS 6248
UP into a cabinet or rack. All Cisco UCS 6200 Series Fabric Interconnects use the same basic installation
procedure.
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Caution
Table 11: Cisco UCS 6248 UP Rack-Mount Kit
Part DescriptionQuantity
Rack-mount brackets2
M4x0.7 x 8-mm Phillips countersink screws12
Rack-mount guides2
10-32 rack nuts10
10-32 x 3/4-inch Phillips pan-head screws10
Slider rails (20 inch minimum to a 36 inch maximum)2
Cisco UCS 6200 Series Fabric Interconnect Hardware Installation Guide
25OL-24475-03
Installing the Cisco UCS 6200 Series Fabric Interconnect
Installing the Cisco UCS 6248 UP Chassis in a Cabinet or Rack
