Supported Transceivers
The fabric interconnect supports SFP+ Ethernet transceivers, SFP transceivers, and SFP Fibre Channel
transceivers. Specifications for these transceivers are at this URL:
http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/installation/note/78_15160.html
SFP+ Transceivers
The high bandwidth of 10-Gigabit Ethernet poses challenges to transmissions that are met by the transceiver
and cabling options supported by the Cisco UCS 6200 platform.
The enhanced SFP+ 10-Gigabit Ethernet transceiver module is a bidirectional device with a transmitter and
receiver in the same physical package. It has a 20-pin connector on the electrical interface and duplex LC
connector on the optical interface.
Table 6: Supported Transceivers
DescriptionCisco SFP
10G SFP+ Fabric extender transceiver module. The
FET-10G SFP is only supported for the 6200 Fabric
Interconnect when the port is setup as a server port.
When it is connected to an uplink port, the FET-10G
SFP transciever module is not supported.
FET-10G
10GBASE-SR SFP+ module (multimode fiber
[MMF])
SFP-10G-SR
10GBASE-LR SFP+ module (single-mode fiber
[SMF])
SFP-10G-LR
10GBASE-CU SFP+ cable 1 m (Twinax cable)SFP-H10GB-CU1M
10GBASE-CU SFP+ cable 3 m (Twinax cable)SFP-H10GB-CU3M
10GBASE-CU SFP+ cable 5 m (Twinax cable)SFP-H10GB-CU5M
10GBASE-CU SFP+ cable 7 m (Twinax cable)SFP-H10GB-ACU7M
10GBASE-CU SFP+ cable 10 m (Twinax cable)SFP-H10GB-ACU10M
1000BASE-T SFPGLC-T
GE SFP, LC connector SX transceiver (MMF)GLC-SX-MM
GE SFP, LC connector LX/LH transceiver (SMF)GLC-LH-SM
1000BASE-T SFP, extended temperature rangeSFP-GE-T
GE SFP, LC connector SX transceiver (MMF),
extended temperature range and digital optical
monitoring (DOM)
SFP-GE-S
Cisco UCS 6200 Series Fabric Interconnect Hardware Installation Guide
