Removing a Cisco UCS 6248 UP
The slider rail and front rack-mount brackets do not have a stop mechanism when sliding in and out. If the
front of the chassis is unfastened from the rack and the chassis slides forward on the slider rails, it may slip
off the end of the rails and fall out of the rack.
Caution
Procedure
Step 1 Ensure that the weight of the Cisco UCS 6248 UP is fully supported and that the chassis is being held by
another person.
Step 2 Remove the two screws holding the grounding cable to the chassis.
Step 3 Disconnect the power cord and the console cables.
Step 4 Disconnect all cables that are connected to SFP+ transceivers.
Step 5 Remove the screws fastening the front rack-mount brackets to the mounting rails.
Step 6 Gently slide the Cisco UCS 6248 UP toward you, off of the slider rails and out of the rack.
Removing a Cisco UCS 6296
The slider rail and front rack-mount brackets do not have a stop mechanism when sliding in and out. If the
front of the chassis is unfastened from the rack and the chassis slides forward on the slider rails, it may slip
off the end of the rails and fall out of the rack.
Caution
Procedure
Step 1 Ensure that the weight of the Cisco UCS 6296 is fully supported and that the chassis is being held by another
person.
Step 2 Remove the two screws holding the grounding cable to the chassis.
Step 3 Disconnect the power cord and the console cables.
Step 4 Disconnect all cables that are connected to SFP+ transceivers.
Step 5 Remove the screws fastening the front rack-mount brackets to the mounting rails.
Step 6 Gently slide the Cisco UCS 6296 toward you, off of the slider rails and out of the rack.
Replacing a Fabric Interconnect
Use the following procedure when you need to replace a single fabric interconnect with the same model of
fabric interconnect.
Cisco UCS 6200 Series Fabric Interconnect Hardware Installation Guide
OL-24475-0348
Installing the Cisco UCS 6200 Series Fabric Interconnect
Removing a Cisco UCS 6248 UP
