Excessively installing and removing an SFP or SFP+ transceiver can shorten its life. Do not remove and install
transceivers unless it is absolutely necessary. We recommend disconnecting cables before installing or removing
transceivers to prevent damage to the cable or transceiver.
Caution
Procedure
Step 1 Attach an ESD wrist strap and follow its instructions for use.
Step 2 If a cable is installed in the transceiver:
a) Record the cable and port connections for later reference.
b) Press the release latch on the cable, grasp the connector near the connection point, and gently pull the
connector from the transceiver.
c) Insert a dust plug into the cable end of the transceiver.
If the transceiver does not remove easily in the next step, push the transceiver completely in and then
ensure that the latch is in the correct position before continuing.
Step 3 Remove the transceiver from the port:
• If the transceiver has a Mylar tab latch, gently pull the tab straight out (do not twist), and then pull the
transceiver out of the port.
• If the transceiver has a bale clasp latch, open the clasp by pressing it downwards, and then pull the
transceiver out of the port.
If you cannot remove the SFP+ transceiver, reseat it by returning the bale clasp to the up
position. Press the SFP+ transceiver inward and upward into the cage. Next, lower the bale
clasp and pull the SFP+ transceiver straight out with a slight upward lifting force. Be careful
not to damage the port cage during this process.
Note
Step 4 Insert a dust cover into the port end of the transceiver and place the transceiver on an antistatic mat or into a
static shielding bag if you plan to return it to the factory.
Step 5 If another transceiver is not being installed, protect the optical cage by inserting a clean cover.
Installing or Removing Cables into SFP or SFP+ Transceivers
Installing a Cable into a Transceiver
To prevent damage to the copper cables, do not place more tension on them than the rated limit and do not
bend to a radius of less than 1 inch if there is no tension in the cable, or 2 inches if there is tension in the cable.
Caution
Cisco UCS 6200 Series Fabric Interconnect Hardware Installation Guide
OL-24475-0360
Connecting the Cisco UCS 6200 Series Fabric Interconnect
Installing or Removing Cables into SFP or SFP+ Transceivers
