The link LEDs for the Fibre Channel ports remain yellow until the ports are enabled, and the LED
for the Ethernet connector port remains off until the port is connected.
Note
Step 10 Try removing and reinstalling a component that is not operating correctly. If it still does not operate correctly,
contact your customer service representative for a replacement.
If you purchased this product through a Cisco reseller, contact the reseller directly for technical
support. If you purchased this product directly from Cisco, contact Cisco Technical Support at this
URL: http://www.cisco.com/en/US/support/tsd_cisco_worldwide_contacts.html.
Note
Step 11 Verify that the system software has booted and that the system has initialized without error messages.
If any problems occur, see Troubleshooting Hardware Components, on page 87. If you cannot resolve an
issue, contact your customer service representative.
Step 12 Complete the worksheets provided in Site Planning and Maintenance Records, on page 81 for future reference.
Step 13 Configure the primary fabric interconnect as described inthe Configuration Guide for the version of Cisco
UCS Manager that you are using. The configuration guides are available at the following URL:
http://www.cisco.com/en/US/products/ps10281/products_installation_and_configuration_guides_list.html
Step 14 Power up, connect the terminal to the console port, and configure the secondary fabric interconnect as described
in the Cisco UCS Manager Configuration Guide.
Replacing or Installing Components
To prevent ESD damage, wear grounding wrist straps during these procedures and handle modules by the
carrier edges only.
Caution
Replacing a Management Daughter Card for a Cisco UCS 6248
This procedure will be necessary if you need to return a Cisco UCS 6248 and receive a replacement bare
chassis, which will not have the management daughter card (UCS-FI-DL2), fans, power supplies, or expansion
modules.
If you need to install or replace a Cisco UCS 6296 fabric interconnect, you do not need to remove and install
the management daughter card. The Cisco UCS 6296 has a nonremovable management daughter card.
Note
Removing a Management Daughter Card
Procedure
Step 1 Prepare an antistatic surface for placing removed components.
Cisco UCS 6200 Series Fabric Interconnect Hardware Installation Guide
39OL-24475-03
Installing the Cisco UCS 6200 Series Fabric Interconnect
Replacing or Installing Components
