Chapter 1 Overview
Front-Panel Description
1-10
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-03
Figure 1-10 LEDs on Catalyst 2950-12, 2950-24, 2950C-24, 2950SX-24, and 2950T-24 Switches
SYST
RPS
DUPLX
MODE
SPEED
UTIL
S TAT
1x
2x
3x
4x
5x
6x
52918
Mode button
Port mode
LEDs
System
LED
Port status
LEDs
RPS
LED
