Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-03
Chapter 2 Installation
Connecting to GBIC Module Ports
When connecting the ports on the Catalyst 2950G-24-EI-DC switches to other
devices, follow these guidelines:
Caution To comply with the intrabuilding lightning surge requirements, intrabuilding
wiring must be shielded, and the shield for the wiring must be grounded at both
ends.
Caution The Catalyst 2950G-24-EI-DC switch is suitable only for intrabuilding or
nonexposed wiring connections.
Connecting to 1000BASE-X GBIC Module Ports
Caution Do not remove the rubber plugs from the GBIC module port or the rubber caps
from the fiber-optic cable until you are ready to connect the cable. The plugs and
caps protect the GBIC module ports and cables from contamination and ambient
light.
After installing the 1000BASE-X GBIC in the GBIC module slot, follow these
steps:
Step 1 Remove the rubber plugs from the GBIC module port, and store them for future
use.
Step 2 Insert the SC connector in the fiber-optic receptacle (see Figure 2-35).
