Chapter 2 Installation
Connecting to GBIC Module Ports
2-38
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-03
Step 3 Insert the other cable end in an SC or ST port on the target device.
Step 4 Observe the port status LED.
The LED turns green when the switch and the target device have an established
link.
The LED turns amber while STP discovers the network topology and searches for
loops. This process takes about 30 seconds, and then the port LED turns green.
If the LED is off, the target device might not be turned on, there might be a cable
problem, or there might be a problem with the adapter installed in the target
device. See Chapter 3, “Troubleshooting,” for solutions to cabling problems.
Step 5 Reconfigure and restart the target device if necessary.
Step 6 Repeat Steps 1 through 5 to connect each port.
Connecting to GBIC Module Ports
These sections describe how to connect to a GBIC module port.
• Connecting to 1000BASE-X GBIC Module Ports, page 2-39
• Connecting to 1000BASE-T GBIC Module Ports, page 2-41
• Connecting to GigaStack GBIC Module Ports, page 2-42
For instructions about how to connect to the CWDM GBIC module ports, refer to
the documentation that came with that GBIC module.
For detailed instructions about installing, removing, and connecting to the GBIC
module (the 1000BASE-X module, the 1000BASE-T module, the CWDM GBIC
module, or the GigaStack module), refer to the GBIC documentation.
