Chapter 2 Installation
Installing the Switch on a Table, Shelf, or Desk
2-20
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-03
Figure 2-17 Attaching the Cable Guide
Installing the Switch on a Table, Shelf, or Desk
Before placing the switch on a table, shelf, or desk, locate the adhesive strip with
rubber feet in the mounting-kit envelope, and attach four rubber feet to the
recessed areas on the switch bottom. Place the switch on a table, shelf, or desk
near an AC power source or DC-input power source.
Start the terminal-emulation software and provide power to the switch. See the
“Powering On the Switch” section for instructions.
Installing the GBIC Modules
Figure 2-18, Figure 2-19, and Figure 2-20 show how to insert a GBIC module in
a GBIC module slot on the switch. For instructions about how to install a CWDM
GBIC module in a GBIC module slot, refer to the documentation that came with
that GBIC module.
For detailed instructions on installing, removing, and cabling the GBIC module
(the 1000BASE-X module, the 1000BASE-T module, the CWDM GBIC module,
or the GigaStack module), refer to your GBIC documentation.
SYST
RPS
DUPLX
MODE
SPEED
UTIL
STAT
1
0
B
a
s
e
-
T
/
1
0
0
B
a
s
e
-
T
X
Catalyst 2950
SE
RIES
45573
Cable guide screw
1x
2x
3x
4x
5x
6x
7x
8x
9x
10x
11x
12x
13x
14x
15x
16x
17x
18x
19x
20x
21x
22x
23x
24x
