Cisco XR 12000 Series Getting Started Guide

3-33
Cisco IOS XR Getting Started Guide for the Cisco XR 12000 Series Router
OL-24755-01
Chapter 3 Configuring General Router Features
Connecting and Communicating with the Router
DETAILED STEPS
Command or Action Purpose
Step 1
Identify the active RP or DRP. Identifies the RP or DRP to which you must connect in the next step.
• This step is not required when the router hosts only one RP.
• On a Cisco XR 12000 Series Router, the active RP is identified by the
alphanumeric display: ACTV RP.
•
Step 2
Connect a terminal to the Console port
of the active RP or DRP.
Establishes a communications path to the router.
• During the initial setup, you can communicate with the router only
through the console port of the active RP.
• Router console port is designed for a serial cable connection to a
terminal or a computer that is running a terminal emulation program.
• Terminal settings are:
– Bits per second: 9600 (default value)
– Data bits: 8
– Parity: None
– Stop bit: 2
– Flow control: None
• For information on the cable requirements for the console port, see the
hardware documentation listed in the “Related Documents” section on
page x.
Step 3
Start the terminal emulation program. (Optional) Prepares a computer for router communications.
• This step is not required if you are connecting through a terminal.
• Terminals send keystrokes to, and receive characters from, another
device. If you connect a computer to the Console port, you must use a
terminal emulation program to communicate with the router. For
instructions on using a terminal emulation program, see the hardware
documentation listed in the “Related Documents” section on page x.
