Chapter 3 Configuring General Router Features
Navigating the Cisco IOS XR Command Modes
Entering EXEC Commands from a Configuration Mode
EXEC commands can be executed from any configuration mode by preceding the command with the do
keyword. Executing EXEC commands from a configuration mode allows you to display the state of the
system without exiting the configuration mode. For example:
RP/0/0/CPU0:router(config)# do show version
Mon May 31 02:52:07.240 DST
Cisco IOS XR Software, Version 4.1.0[Default]
Copyright (c) 2010 by Cisco Systems, Inc.
ROM: System Bootstrap, Version 12.0(20090226:235859) [rtauro-sw30346-33S 1.23dev(0.35)]
DEVELOPMENT
SOFTWARE
Copyright (c) 1994-2009 by cisco Systems, Inc.
PE6_C12406 uptime is 2 weeks, 6 days, 10 hours, 4 minutes
System image file is "disk0:c12k-os-mbi-4.1.0/mbiprp-rp.vm"
Router submode
configuration
Router configuration submodes are accessed from router configuration mode. The following
command syntax is used for entering router address family configuration submode:
RP/0/0/CPU0:router(config)# router bgp 140
RP/0/0/CPU0:router(config-bgp)# address-family ipv4 multicast
RP/0/0/CPU0:router(config-bgp-af)#
For more information, see the following Cisco documents:
• Cisco IOS XR Routing Configuration Reference for the Cisco XR 12000 Series Router
• Cisco IOS XR Routing Command Reference for the Cisco XR 12000 Series Router
•
ROM Monitor
(ROMMON)
The ROM Monitor is a bootstrap program that initializes the hardware and boots the system when a
router is powered on or reset. ROM Monitor mode is also known as ROMMON, which reflects the
CLI prompt for the mode.
rommon B1>
During normal operation, users do not interact with ROMMON. This mode is accessed only by
manually interrupting the boot process and placing the system in ROMMON. Once in ROMMON,
you can perform ROM Monitor tasks, including reinstallation of the Cisco IOS XR software,
password recovery, and other diagnostic tasks.
The ROM Monitor CLI mode is accessible only from a terminal connected directly to the Console
port of the primary RP, a terminal-modem connection to the AUX port, or through a terminal server.
For information and instructions on using ROM Monitor mode, see Cisco IOS XR ROM Monitor
Guide for the Cisco XR 12000 Series Router.
For information and instructions on using ROM Monitor mode, see Cisco IOS XR ROM Monitor
Guide for information and instructions on using ROM Monitor mode.
Table 3-4 Common Command Modes and CLI prompts (continued)
Command Mode Description
