Cisco XR 12000 Series Getting Started Guide

3-70
Cisco IOS XR Getting Started Guide for the Cisco XR 12000 Series Router
OL-24755-01
Chapter 3 Configuring General Router Features
Displaying the Available Management Ethernet Interfaces
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/0/CPU0:router# configure
Enters global configuration mode.
Step 2
interface MgmtEthrack/slot/CPU0/port
Example:
RP/0/0/CPU0:router(config)# interface
MgmtEth0/RP0/CPU0/0
Enters interface configuration mode and specifies the
Management Ethernet interface of the primary RP.
• The syntax is
interface typerack/slot/module/port:
Table 3-6 describes the command parameters.
Step 3
ipv4 address ipv4-address subnet-mask
Example:
RP/0/0/CPU0:router(config-if)# ipv4 address
10.1.1.1 255.0.0.0
Assigns an IP address and subnet mask to the interface.
Step 4
no shutdown
Example:
RP/0/0/CPU0:router(config-if)# no shutdown
Places the interface in an “up” state.
Step 5
exit
Exits the Management Ethernet interface configuration
mode.
Step 6
router static address-family ipv4 unicast
0.0.0.0/0 default-gateway
Example:
RP/0/0/CPU0:router (config)# router static
address-family ipv4 unicast 0.0.0.0/0 12.25.0.1
Configures a default route to use for communications with
devices on other networks.
• Replace default-gateway with the IP address of the
local gateway that can be used to reach other
networks.
• This default route applies to all interfaces. You might
need to configure additional static routes to support
your network. For more information on configuring
static routes, see Cisco IOS XR Routing
Configuration Guide for the Cisco XR 12000 Series
Router.
Step 7
commit
Example:
RP/0/0/CPU0:(config)# commit
Commits the target configuration to the running
configuration.
