86
Operating Manual
Recommendation for Selection of RSP Offset Creasing Matrices
Thickness of material with lines with felxible dies
0.10 mm 0.3 × 0.7 mm 0.2 × 0.8 mm
0.15 mm 0.3 × 0.8 mm 0.2 × 0.8 mm
0.20 mm 0.3 × 1.0 mm 0.2 × 1.0 mm
0.25 mm 0.3 × 1.0 mm 0.2 × 1.0 mm
0.30 mm 0.3 × 1.2 mm 0.2 × 1.2 mm
0.35 mm - 0.50 mm 0.3 × 1.3 mm –
Note:
The value mentioned above are guide numbers and are therefore not binding.
The following factors have an important inuence on the correct creasing strip:
• Pressure supply
• Hardness of material to be imprinted
• Humidity of material to be imprinted
• Makeready of the base blanked
