Clarion NX700 User Manual

17
2.3.4 Status information and hidden controls on the map
The following information appears in the rounded field in the top left corner, the Turn Preview field. When
tapping this area, the result depends on the information currently shown.
Icon Information Details Action
There is no active route
in Simple mode
If there is no route to be
navigated in Simple mode,
this icon appears in the Turn
Preview field.
Tap this area to open Find
Address.
There is no active route
in Advanced mode
If there is no route to be
navigated in
A
dvanced
mode, this icon appears in
the Turn Preview field.
Tap this area to open Find.
,
There is no valid GPS
position.
If an active route exists, and
there is no valid GPS
position, the view of the sky
above you is shown with
colored dots for each
satellite. Some dots need to
turn green to be able to
navigate.
Tap this area to open the Route
Information screen.
If the icon is a static
picture, route
calculation is needed
GPS position and an active
route are available, but
automatic off-route
recalculation is switched off,
and you deviated from the
route.
Tap this area to make Clarion
Mobile Map recalculate the
recommended route.
If the icon is animated,
route calculation is in
progress
Clarion Mobile Map is
calculating or recalculating
the route.
Nothing happens if you tap this
area of the screen.
,
Next route event (next
maneuver)
GPS position and an active
route are available, and you
navigate the recommended
route. This area gives you
information about the type
and distance of the next
route event.
Tap this area to open the Route
Information screen.
