Clear-Com EclipseHX Series User Manual

User Guide | Eclipse HX-Median
Page 153
Output Format
RS-422 @ 2400 to 19200 kb/s
Input Termination
100 ohm ± 10%
Output Termination
None; expected at User Panel
Isolation
None; expected at User Panel
Table 50: Data interface: 16 bi-directional
14.27 Backplane connector: FCI/BERG Metral
Category
Measures / comments
Port Connector
RJ-45 to Clear-Com standard pinout
Transmission Distance
3000 ft. (1000 m) maximum
Table 51: Data interface: 16 bi-directional
14.28 System programming
Category
Measures / comments
Group Calls
100
Number of Grouped Ports
4000 maximum
Conferences per Matrix
199
IFB per Matrix
100
Priority Levels
5
Isolates
Any crosspoint
Listen Level Control
0.71 dB steps
Input Level Control
0.355 dB steps
Output Level Control
0.355 dB steps
VOX Input Detection
Threshold
0 dB to – 45 dB adjustable
Table 52: System programming
14.29 Minimum PC requirements (for EHX software)
Specification
Description / Value
Processor
1 GHz
Memory
1GB RAM
Hard disk
32 bit:
1GB minimum
