CleaverBrooks CFC ClearFire - Model CFC Minimum Room Clearance Dimensions

Model CFC ClearFire Commercial Boilers
36 Rev. 05-2012
Figure B5-28. Model CFC Minimum Room Clearance Dimensions
Seismic Legs Seismic mounting details shown below.
Figure B5-29. CFC Seismic Mounting
DIM Inches
Top Clearance A 14
Side Clearance B 20
Backway C 20
Front D 36
Between Boilers E 3
C
B
D
B
E
CFC 500-2500 CFC 3300
