Figure B5-41. Domestic Water with On/Off and 3-Way Valves
ClearFire Full
Condensing
ClearFire Full
Condensing
To Condensate Drain
To Sanitary Drain
System Returns
Domestic Co
l
Water In
Domestic
Water
Domestic
Water Pump
Return Header
Boiler Drain
Domestic
Water Supply
Heating System
Pumps
System Supply & Returns
System Supply
Header
Expansion
Tank
Water
Makeup
On-Off
Valves
