Model CFC ClearFire Commercial Boilers

62 Rev. 05-2012

Vertical Venting

Inside Combustion

Air

See Figure B5-52.

Figure B5-52. Inside Air - Vertical Vent

As noted in Paragraph A above, these installations use air from within the boiler

room for combustion. The same recommendations apply as noted in Paragraph A

above and also, the recommendations on flue vent sizing according to Table B5-25.

CFC Boiler

Flue Gas Vent

24"

Minimum

10'-0" or Less

48"

Minimum

Termination
