CleaverBrooks CFC ClearFire - Pipe System, Typical (Reverse-Return)

Figure B5-34. 2 Pipe System, Typical (reverse-return)
CFC
2
1
1
PRIMARY ZONE (WITH THERMOSTAT)-
THERMOSTAT CONTROLS BOILER AND CIRCULATOR.
2
HEATING UNITS WITH
THERMOSTATIC VALVES.
