SELECTING THE OPERATING MODE
The operating mode is determined by the indoor unit. In fact, the voltage free contact on the indoor unit, suitably connected
to the heat pump circuit (see wiring diagram enclosed), is used to select cooling or heating operating mode.
Control probe
Alarm active
Set Point : SEt Cooling Set Label: Coo Cooling Set Value
Input codes: t01- t06
Input codes: I01-I11
Active alarm codes: E00-E46
Antifreeze par: Fro
Punp par.: PUP
Alarm par.: ALL
Fan par.: FAn
Compressor Par.: CP
Configuration par.: CnF
Comp. hours: OH1-OH2
Password value
Pump hours: OHP
Analogical input: tP
Alarms: Err
Digital inputs: Id
Parameters: PAr
Password: PSS
Operating hours: OHr
Par. index H01-H52
Digital input status
Analogical input values
Par. index r01-r15
Par. index P01-P03
Par. index A01-A26
Par. index F01-F25
Par. index C01-C07
Number of hours
Number of hours
Parameter value
Parameter value
Parameter value
Parameter value
Parameter value
Parameter value
Level 0 Level 3Level 2Level 1 Level 4
Par. index d01-d09Antifreeze par: dFr Parameter value
To move around the levels press the “Mode” and “on off” buttons together.
1 - Pressing and releasing both buttons within 2 seconds goes down one level in the configuration
menu.
2 - Holding both buttons for more than 2 seconds goes up one level in the configuration menu.
3 - If the last level of a menu is displayed, pressing and releasing both buttons within 2 seconds
goes back one level.
