Setup with the web interface for PC
98-144390-C Chapter 4: Setup and operation 4-5
• To get an overview over the submenus available, click SITE MAP in the
navigation pane. Click on items in the site map to go directly to the relevant location.
Status field in the icon bar
The top bar shows the current signal strength and the current status of the antenna.
Examples:
•Antenna software upload
• Antenna POST (Power-On Self Test)
• Ready (waiting for data from the modem or no satellite profile selected)
Deployed idle (antenna ready)
•Manual pointing
• Acquisition OK (signal from the GX satellite acquired)
• Safe mode (error, followed by an error description)
Sections on the Dashboard
You can give access to some configuration settings for users that are not
administrators. For information see User permissions (guest login) on page 4-
12.
DASHBOARD Description
GNSS position Current position, reported by the GNSS module
Satellite profile Name of the currently active satellite profile.
Satellite position Position of the satellite selected in Satellite profile.
RX RF frequency Ka band receiving frequency, auto-selected by modem
Tuner signal strength Current tuner signal strength
Tuner mode GSC (GX) or Narrow band
Tracking RF frequency Current RF tracking frequency
ACU part name, Antenna
part name, ACU serial
number, Antenna serial
number, Software
version
Part names, serial numbers for antenna, software version of the
EXPLORER 3075GX.
Table 4-2: Web interface: DASHBOARD
