List of events
B-2 Appendix B: System messages 98-144390-C
B.2 List of events
Error code
(ID)
Severity Description Explanation
08065-0 ADM WARNING GNSS data Missing GPS data (fix).
08067-0 ADM ERROR PCB temperature ADM temperature too high. The ACU is not
equipped with a fan, so make sure there is
compliance with the environmental
specifications.
0806A-0 ADM WARNING VMU connection The ACU has lost connection with the sat
modem.
0806C-0 ADM ERROR VMU frequency setup There is a mismatch in the frequency setup.
Wait 5 minutes. If the error persists power-
cycle the terminal.
0806E-0 ADM ERROR VMU 10 MHz reference The Rx or Tx reference signal is not present.
Make sure Rx/Tx cable is connected and that
the VMU is configured to output the RX/TX
reference signal.
08078-0 ADM WARNING VMU TX frequency invalid The modem unit provided a TX frequency of
zero. Tx will not work.
0807F-0 ADM WARNING Local administration
enabled
Local administration mode is currently enabled.
This allows login without providing the admin
password. Will be disabled after 1 hour or next
reboot.
08080-0 ADM WARNING Satellite info mismatch Current chosen manual satellite information
does not match information from the modem.
Please choose another satellite for manual
pointing.
08104-0 ADM ERROR Antenna communication The ACU cannot communicate with the
antenna. Check cable and antenna.
08107-0 ADM ERROR ADM FPGA load The ADM FPGA cannot be initialised and
loaded.
0810A-0 ADM ERROR ADM production data Production data has been corrupted.
0810C-0 ADM ERROR File system integrity One or more file system partitions are corrupt.
You may have lost your settings and collected
statistics. If restarting the system does not
help, contact your service partner.
Table B-1: Event messages
