Web interface for tablet and smartphone
98-144390-C Chapter 4: Setup and operation 4-21
Example: EVENT 1/4*: This is the first event out of a list of 4 and there has been a
change in the list. EVENT 1/4 will always be shown, the * indicates that there
has been a change.
4.2.4 Brightness of the display
To adjust the brightness do the following:
1. Press and hold OK for a short moment until BRIGHTNESS XXX% is displayed (XXX is the
current brightness value).
2. Hold OK + press to brighten or to darken display.
3. Release OK to leave the brightness menu.
4.3 Web interface for tablet and smartphone
If you access the web interface from a smartphone or tablet the mobile web interface is
displayed. It has the following basic functions:
• Activate a satellite profile
• See status and events
• Access the web interface (PC version)
To access the mobile web interface, do as follows
1. Press the On/Off button to power up the EXPLORER 3075GX.
2. Connect your smartphone or tablet to the WLAN of the EXPLORER 3075GX. For details
on WLAN setup. see WLAN settings on page 4-9.
3. Open your Internet browser and enter the IP address of the ACU. The default IP address
is http://192.168.0.1. The mobile web interface opens.
EVENT Description
<EVENT> In this menu all active events are listed. Use and
to go through the
active events.
Events can be of the type WARNING or ERROR.
If a new event occurs or there is a change in the event list while you are in the
EVENTS menu, a * is shown in the upper left corner of the display, next to
the menu name. Press OK to update the EVENTS list, the * will be removed.
A > means the event text is longer than the display. Press > to see the
remaining text.
Table 4-13: EVENTS menu
