Specifications
A-2 Appendix A: Technical specifications 98-144390-C
Weights and measures
Terminal 21.5 kg (47.5 lbs)
Transport cases (2) Airline checkable
Case with base unit and RF assembly
Dimensions (L/W/D)
Weight
62.5/50/29.7 cm (24.6/19.7/11.7 in)
<23 kg (50.7 lbs)
Case with reflector panels, tripod and cables
Dimensions (L/W/D)
Weight
79.5/51.8/31 cm (31.3/20.4/12.2 in)
<23 kg (50.7 lbs)
Environmental characteristics
Wind Speed - Operational 48 km/h (30 mph) gusts up to 72 km/h (45
mph) (anchored)
Survival 129 km/h (80 mph)
Temperature - Operational, antenna -25° to +55°C (-13° to +131°F)
Temperature - Storage. antenna -40° to +80°C (-40° to +176°F)
Rain <100 mm/hr
Humidity 0 to 100% (condensing)
IP class IP65
Cable requirements for TX and RX cables
Coax RF Loss <3 dB @ 50 MHz
<10 dB @ 2 GHz
DC resistance <1 Ohm
After changing the TX cable you must make a One Touch Commissioning. See
GX Modem: One Touch Commissioning (OTC) on page 5-6.
