Keypad and display menus
98-144390-A Chapter 4: Setup and operation 4-17
Top-level menu
Menu descriptions
Top-level menu Description
MANUAL POINTING Shows current azimuth, elevation and signal strength.
MAIN View with current status of the EXPLORER 3075GX. Example when
logged on to the satellite:
This view is displayed after a time out of 10 minutes. Press any key
(except left arrow) to enter the menu at MAIN.
New events are shown in this display. If an event is displayed, press
OK to jump directly to the menu EVENTS for viewing the currently
active events.
ANTENNA Shows the current antenna parameters, position, software version
and serial numbers of the ADU and ACU.
MODEM Modem information, including modem LED status
SATELLITE Current satellite information. This information is selected using the
web interface.
NETWORK Shows the IP addresses and netmasks of the LAN connectors and
the management mask.
EVENTS View system events. Active events are shown as: X ACTIVE EVENTS
in the MAIN display. Press OK to update the list.
Table 4-5: Top-level menus
0DLQ1$9*+0'01(72./$1±
$&48,6,7,212.
6$7:5;/+7;0$5
MANUAL POINTING Description
AZI ELE Current values for azimuth and elevation
Table 4-6: MANUAL POINTING menu
ANTENNA Description
POINTING ANTENNA STATE: Current state of the antenna, e.g. TRACKING
ELEVATION: Current elevation angle of the antenna
AZIMUTH: Current azimuth of the antenna, with reference to North
GPS LATITUDE: current latitude, read from GNSS module.
LONGITUDE: current longitude, read from GNSS module.
FIX TYPE: 2D or 3D or NONE
COMPASS Current orientation of the antenna.
VERSIONS Current software version.
SERIAL NUMBERS Serial number of the EXPLORER 3075GX and an Inmarsat serial
number.
Table 4-7: ANTENNA menu
