Keypad and display menus
4-18 Chapter 4: Setup and operation 98-144390-A
MODEM Description
MODEM TYPE Current modem type.
TX ENABLE On or off, information delivered by the connected GX modem.
RX LOCK On or off, information delivered by the connected GX modem.
SIGNAL LEVEL Current input signal level from the GX modem, in dB.
NET LED Modem status. Steady or flashing green/yellow/red, OFF
STAT LED
TX LED
RX1 LED
RX2 LED
PWR LED
TEMP LED
FAN LED
Table 4-8: MODEM menu
SATELLITE Description
POSITION Current satellite position.
RX FREQ Current RX frequency.
LNB LO LNB LO frequency
BUC LO BUC LO frequency
Table 4-9: SATELLITE menu
NETWORK Description
PORT1 IP Current IP address for LAN1 (service port).
PORT1 MASK Current netmask for LAN1.
DEFAULT GATEWAY Current default gateway.
Table 4-10: NETWORK menu
EVENT Description
<EVENT> In this menu all active events are listed. Use and
to go through the
active events.
Events can be of the type WARNING or ERROR.
If a new event occurs or there is a change in the event list while you are in the
EVENTS menu, a * is shown in the upper left corner of the display, next to
the menu name. Press OK to update the EVENTS list, the * will be removed.
A > means the event text is longer than the display. Press > to see the
remaining text.
Table 4-11: EVENTS menu
