List of events
B-4 Appendix B: System messages 98-144390-A
09000-0 KDM ERROR KDM 3V3 supply Internal 3V3 voltage supply error in the
KDM.
09001-0 KDM ERROR KDM 12V supply Internal 12V voltage supply error in the
KDM.
09002-0 KDM ERROR KDM display Display hardware error in the KDM.
09010-0 KDM ERROR KDM link/SW version Link to the KDM module could not be
established. Either the KDM board is
malfunctioning, or - if the system software
has just been updated - the software is too
old and is not compatible with the KDM
hardware.
Error code
(ID)
Severity Description Explanation
Table B-1: Event messages (Continued)
Event ID Severity Description Explanation
0C002 Error GNSS position/velocity Not detecting any GPS satellite
0C007 Error SNR communication SSI values are not being received
0C013 Error No transponder found The acquisition algorithm could not identify a
transponder
Table B-2: Event messages of the antenna
