Chapter 1: Introduction to EXPLORER 540
98-148232-E Features and interfaces of the EXPLORER 540 3
Interfaces
There are no external connectors on the EXPLORER 540. The following interfaces are
contained inside the compartment at the back of the EXPLORER 540:
LAN interface with Power over Ethernet (PoE) input
I/O ports for control of power save mode and for remote control/status
Power input from:
• PoE+ (IEEE 802.3at type 2 class 4, 25 W) or
• separate DC power source, e.g. a battery (max. range 10.5-32 VDC)
USB interface for connection to EXPLORER 540 LTE Modem
For specifications on the interfaces, see Interfaces specifications on page 115.
Approvals/certificates
Country Approval / certificate
EU CE
US FCC
Canada IC
Australia / New Zealand RCM
Russia Type approval certificate in the
field of communications
Japan Radio Law
International GMPCS
International C1D2
International Inmarsat Class 2 Type Approved
and BGAN M2M Certified
