COBHAM EXPLORER 540 - Optional EXPLORER 540 LTE Modem

Appendix A: Technical specifications
98-148232-E Optional EXPLORER 540 LTE Modem 121
Optional EXPLORER 540 LTE Modem
Specifications
Product numbers
Technology and frequency bands
Part number Product
403715A-101 EXPLORER 540 LTE Modem (North America)
403715A-102 EXPLORER 540 LTE Modem (Europe / APAC)
403715A-110 LTE Modem Extension Kit
- For mounting the LTE Modem outside the EXPLORER 540
Item Specification
LTE
(4G)
150 Mbps downlink, 50 Mbps uplink (Cat. 4)
Channel Bandwidths: 1.4 - 20 Mhz
MIMO 2x2
UMTS/DC-HSPA+
(3G)
42 Mbps downlink, 5.76 Mbps uplink
GSM
(2G)
GPRS & EDGE Class 12
Model
LTE
module
Region
Access Technology
LTE Bands UMTS Bands GSM Bands
403715A-101 ublox
TOBY-L200
North
America
2,4
a
,5,7
a. Operation in this LTE band requires that the EXPLORER 540 LTE Modem is installed in the external housing.
850/900/AWS/
1900/2100
850/900/
1800/1900
403715A-102 ublox
TOBY-L210
Europe /
APAC
1,3
a
,5,7,8,20 850/900/
1900/2100
850/900/
1800/1900
