Appendix A: Technical specifications
98-148232-E Optional EXPLORER 540 LTE Modem 122
Environmental and mechanical specifications
Outline drawing, external modem
Dimensions are in millimeter
Item Specification
Weight 380 g
Dimensions 85 mm x 85 mm x 40 mm
Operating Temperature –40 to +85°C (extended range)
Industrial Grade Automotive
Ingress Protection IP66
69.5
83.8
95.4
M5 Thread x 1 place
Screw depth max. 10 mm
M6 Thread x 4 places
Screw depth max. 10 mm
M20 x 1.5 Thread for cable gland
50
47.8
22.8
50
