Chapter 4: Configuration with web interface
98-148232-E Advanced settings 79
2. Click OK.
The terminal will now restart and start up with the factory settings. The installation process
is also restarted.
SIM PIN for BGAN
To enable or disable the use of a SIM PIN
To enable or disable the use of a PIN to access the BGAN network, do as follows:
1. Under Advanced, select SIM.
2. Select Enable/disable SIM PIN.
3. Under Enable/Disable PIN select or clear the box next to Require PIN on startup.
• If you clear the box, you can access and use the terminal without entering a PIN
• If you select the box, you must enter a PIN on startup before you can make calls or data
sessions
4. If you selected Require PIN on startup, type in the PIN next to Enter current PIN.
5. Click Save.
The new PIN settings will take effect at next power on.
To change the SIM PIN
To change the PIN used to access the BGAN network, do as follows:
1. Under Advanced, select SIM.
2. Select Change SIM PIN.
3. Under Change PIN type in the Current PIN.
4. Type in the New PIN and retype it on the next line.
5. Click Save. The new PIN settings will take effect at next power on.
Auto SIM PIN validation
The Auto SIM PIN validation feature allows the EXPLORER 540 to automatically send the PIN
to the SIM at power up. This enables the SIM to be PIN locked (to prevent unauthorized re-use
of the SIM elsewhere), while still allowing the EXPLORER 540 to connect to the BGAN network
without using a PIN.
When this feature is enabled, the PIN you enter when setting the Auto SIM PIN validation
feature is encrypted and stored locally in the EXPLORER 540. The next time the EXPLORER 540
restarts, the terminal decrypts the PIN and automatically sends it to the SIM without user
intervention.
The SIM PIN must be enabled before you can change it.
