Sending calls
HF SSB transceiver user guide 4-37
Action Notes
11.
To view the results of
your status call, check
the call memory for the
types of display shown
below.
Call memory holds the
information that the remote
transceiver sent back to you.
In call memory the information
scrolls across the screen after a
few seconds (see Chapter 5,
Reviewing calls held in
memory).
Remote diagnostics call
display:
CALL
Review:1 Chan:208
185074 23/03 20:18
Rx=11.2V Tx=10.3V Gai
DELETE
nnnnnn dd/mm hh:mm
Address of caller / date time
Rx=nn.nV
Voltage in receive
Tx=nn.nV
Voltage in transmit
S1=nnn
µ
V
Signal strength of received call
(µV EMF)
S2=nnn
µ
V
Signal strength two seconds after
call was received (µV EMF)
Gain=On/Off
RF gain setting
SWR=n.n
SWR of the antenna
Pwr=nnnW
Power output of the transmitter
(Watts)
PA=400
Indicates transceiver has 400W
PA
Sending calls
HF SSB transceiver user guide 4-37
Action Notes
11.
To view the results of
your status call, check
the call memory for the
types of display shown
below.
Call memory holds the
information that the remote
transceiver sent back to you.
In call memory the information
scrolls across the screen after a
few seconds (see Chapter 5,
Reviewing calls held in
memory).
Remote diagnostics call
display:
CALL
Review:1 Chan:208
185074 23/03 20:18
Rx=11.2V Tx=10.3V Gai
DELETE
nnnnnn dd/mm hh:mm
Address of caller / date time
Rx=nn.nV
Voltage in receive
Tx=nn.nV
Voltage in transmit
S1=nnn
µ
V
Signal strength of received call
(µV EMF)
S2=nnn
µ
V
Signal strength two seconds after
call was received (µV EMF)
Gain=On/Off
RF gain setting
SWR=n.n
SWR of the antenna
Pwr=nnnW
Power output of the transmitter
(Watts)
PA=400
Indicates transceiver has 400W
PA
