Overview
HF SSB transceiver user guide 2-13
Part of Display Function
4.
2100
Shows the kHz transmit/receive frequency of the
channel. For 2-frequency simplex channels the
receive frequency is normally displayed—the
transmit frequency is displayed during transmission.
You can display both frequencies at the same time
(refer to the HF SSB transceiver reference manual,
Chapter 6, Display frequency).
5.
Indicates the current function of the
button on
the front panel.
6.
Indicates the signal strength of the signal being
transmitted or received.
7.
Tx/Rx
Indicates whether the transceiver is currently
transmitting (Tx) or receiving (Rx).
8.
422
Shows the channel number.
9.
Indicates the current function of the
button on
the front panel. For example, if the current channel
is a transmit channel,
is displayed to show that
pressing the
button will send a call.
10.
.
Indicates that the channel is unprotected. If this
marker is not displayed, the channel is protected
from deletion and all changes (except for the
channel comment).
11.
Indicates whether
HI
(high) or
LO
(low) power is
selected.
Overview
HF SSB transceiver user guide 2-13
Part of Display Function
4.
2100
Shows the kHz transmit/receive frequency of the
channel. For 2-frequency simplex channels the
receive frequency is normally displayed—the
transmit frequency is displayed during transmission.
You can display both frequencies at the same time
(refer to the HF SSB transceiver reference manual,
Chapter 6, Display frequency).
5.
Indicates the current function of the
button on
the front panel.
6.
Indicates the signal strength of the signal being
transmitted or received.
7.
Tx/Rx
Indicates whether the transceiver is currently
transmitting (Tx) or receiving (Rx).
8.
422
Shows the channel number.
9.
Indicates the current function of the
button on
the front panel. For example, if the current channel
is a transmit channel,
is displayed to show that
pressing the
button will send a call.
10.
.
Indicates that the channel is unprotected. If this
marker is not displayed, the channel is protected
from deletion and all changes (except for the
channel comment).
11.
Indicates whether
HI
(high) or
LO
(low) power is
selected.
