C004386_03_CR2500_ User_Manual - 45
Save Settings
5.1 - Set Targeting Zone Tolerances
50 Most Accurate 75 100 125
1600 (Default)
150 200 400 Least Accurate
The targeting tolerance is the zone around the green LED which is eligible for decoding. The values of each of the following
codes are the percent tolerance based on the size of the barcode. As the targeting tolerance becomes smaller the targeting
green LED must be more centered in the symbol being read. Conversely, as the targeting tolerance gets larger there is less
precision needed with the green LED. If there is more than one decodable code in the fi eld of the, the symbol closest to the
targeting green LED will be decoded.
