Place the bottom edge of the gasket onto the underside of the main module. Press on the top edge to fully seat
the gasket:
Note: The flat side of the gasket (marked as "Front" in the image above) has to face outside.
WARNING: Do not touch any electrical component.
4. Reattach the I/O connector module to the main module.
5. Reinstall the washers and loosely fasten the modules together with the two T10 cap nuts, but do not tighten.
