Cognex DataMan 262 - Dataman 260 Readers with a 16 MM Lens

l outer: DM262
l inner: DM260
DataMan 260 Readers with a 16 mm Lens
The following tables show the FoV widths of the 16 mm lens at various distances.
DM260
Distances in mm 2D min. code 1D min. code
80 3 MIL 2 MIL
150 5 MIL 3 MIL
190 6 MIL 4 MIL
225 7 MIL 4 MIL
375 12 MIL 5 MIL
500 15 MIL 10 MIL
1 m 25 MIL 15MIL
DM262
Distances in mm 2D min. code 1D min. code
80 2 MIL 2 MIL
150 3 MIL 2 MIL
190 4 MIL 2 MIL
225 4 MIL 3 MIL
375 7 MIL 4 MIL
500 10 MIL 6 MIL
1 m 20 MIL 15MIL
34
Setting Up Your DataMan 260
