ECON-4 1.4.0 Global Guide
62
Setpoint group Main PID Related FW
1.4.0
configured ECON-4
ADVextension module
Range [units] 0 – 100.0 %
Default value 80% Force value NO
Step 0.1 %
Comm object 13982 Related applications ALL
Setpoint visibility WinScope only
Description
There is 5 load bands defined via setpoints Load 1 to Load 5 and different Load gain, Load Int, Load der and
Load anticip setpoints are active in each band.
Load 4
6 back to List of setpoints
Setpoint group Main PID Related FW
1.4.0
configured ECON-4 extension
module
Range [units] 0.0 - 100.0 [%]
Default value 0% Force value NO
Step 0.1 %
Comm object 7182 Related applications ALL
Setpoint visibility Always
Description
Droop of speed governor. The governor lovers the speed reference by Droop percent of the Nominal RPM
(page 46) over the range from zero to MaxFuel (page 63).
Droop
6 back to List of setpoints
