InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
7 Function description
7.1 Overview
HINT
There are numerous built-in functions in the controller that can be modified or combined to produce
new functions for specific uses. Note that it is not possible to describe all the combinations or
modifications in detail in this manual. Users are encouraged to find new way of how to use existing
functions to their benefit.
Click this symbol at the functions for more information on particular complex function.
FUNCTION NAME
(ALPHABETICAL
ORDER)
RELATED SETPOINTS, INPUTS AND
OUTPUTS
Access locking
from various
sources
There are vast options regarding
access restrictions in the controller. It
is possible to lock:
Buttons for various commands
on the terminal.
External buttons for various
commands on binary inputs.
Built-in terminal or terminal #1 to
monitoring mode only.
External local terminal or
terminal #2 to monitoring mode
only.
All external remote terminals (PC
connection, displays on all buses
except on RS485 dedicated
port).
Local buttons
ACCESSLOCK INT
ACCESSLOCK D#2
ACCESSLOCK D#3
ACCESSLOCK EXT
FAULTRESBUTTON
HORNRESBUTTON
LCBBUTTON
Active call,
emailing and
SMS service
AA
This function allows user to choose
under which conditions active emailing
happens, what is the type of the
message and separate addresses or
numbers. Learn more about these
functions in a separate chapter.
History record
Alarm only
Warning
Breaker open
BrkOpn w/Reset
AcallCH1-Type
AcallCH2-Type
AcallCH3-Type
AcallCH1-Addr
AcallCH2-Addr
AcallCH3-Addr
ActCallAttempt
Acall+SMS lang
ISSUEACTCALLC1
ISSUEACTCALLC2
ISSUEACTCALLC3
SMTP authent
SMTP user name
SMTP password
SMTP address
Contr mailbox
Time zone
Alternative
brightness for
built-in
InteliGen
display.
It is possible to choose two different
levels of brightness and switch them with
logical binary input.
