ComAp IM-NT - Group: Sync Ctrl

InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
170
12.2.8.35 Setpoint: GroupLinkLeft
Group
Pwr management
Range [units]
COMMON (=1), 2 .. 32 [-]
Related FW
3.0
Description
NOTE:
In MCB/MGCB application both GroupLinkLeft and GroupLinkRight should be
set to 1 (=COMMON).
If the input GroupLink of this particular controller is used to provide the "group
link" information for two logical groups, then this setpoint is used to select
which group is located at the left side of the group link breaker (bus tie
breaker). If this particular controller is not used for the group link function
adjust this setpoint to 1 (COMMON).
12.2.8.36 Setpoint: GroupLinkRight
Group
Pwr management
Range [units]
COMMON (=1), 2 .. 32 [-]
Related FW
3.0
Description
NOTE:
In MCB/MGCB application both GroupLinkLeft and GroupLinkRight should be
set to 1 (=COMMON).
If the input GroupLink of this particular controller is used to provide the "group
link" information for two logical groups, then this setpoint is used to select
which group is located at the right side of the group link breaker (bus tie
breaker). If this particular controller is not used for the group link function
adjust this setpoint to 1 (COMMON).
12.2.9 Group: Sync ctrl
12.2.9.1 Setpoint: Voltage window
Group
Sync ctrl
Range [units]
0.0 .. 100.0 [%]
Related FW
3.0
Force value
YES
