ComAp Inteli Mains NTC BaseBox User Manual

Communication Guide, ©ComAp – March 2014 116
IGS-NT Communication Guide 03-2014.pdf
Bit 3-5 ................. Protection #1 Level 2
Value Meaning
------------------------------------------------------------------
0 Level 2 inactive
2 Level 2 active, confirmed
3 Level 2 active, blocked
4 Level 2 previously active, not confirmed yet
6 Level 2 active, not confirmed yet
7 Level 2 active, not confirmed yet, blocked
Bit 6-7 ................. Protection #1 Sensor failure
Value Meaning
------------------------------------------------------------------
0 Sensor failure not active
1 Sensor failure active, confirmed
2 Sensor failure previously active, not confirmed yet
3 Sensor failure active, not confirmed yet
Bit 8-10 ................. Protection #2 Level 1
Value Meaning
------------------------------------------------------------------
0 Level 1 inactive
2 Level 1 active, confirmed
3 Level 1 active, blocked
4 Level 1 previously active, not confirmed yet
6 Level 1 active, not confirmed yet
7 Level 1 active, not confirmed yet, blocked
Bit 11-13 ................. Protection #2 Level 2
Value Meaning
------------------------------------------------------------------
0 Level 2 inactive
2 Level 2 active, confirmed
3 Level 2 active, blocked
4 Level 2 previously active, not confirmed yet
6 Level 2 active, not confirmed yet
7 Level 2 active, not confirmed yet, blocked
Bit 14-15 ................. Protection #2 Sensor failure
Value Meaning
------------------------------------------------------------------
0 Sensor failure not active
1 Sensor failure active, confirmed (or not configured as protection)
2 Sensor failure previously active, not confirmed yet
3 Sensor failure active, not confirmed yet
Example
Register Protection#2 Protection#1
=============================================================================
45754 Warning 7 Warning 8
45755 Warning 9 Warning 10
45756 SD 11 SD 12
45863 Oil press Water temp
45864 Fuel level N/A
45925 BIN 1 BIN 2
45926 BIN 3 BIN 4
Register number 45863 carries informations about states of protections Oil press and Water temp.
For undersanding of particular bit meaning use previous register map according table bellow. The first
