Data type
Meaning
Number of
registers
Data part of the communication
function
1
Integer8
Signed integer – 8 bits
1
MSB1 = sign extension LSB1
LSB1 = comm. object value
Unsigned8
Unsigned integer – 8 bits
1
MSB1 = 0
LSB1 = comm. object value
Integer16
Signed integer – 16 bits
1
MSB1 = comm. object value, bits 15-8
LSB1 = comm. object value, bits 7-0
Unsigned16
Unsigned integer – 16 bits
1
MSB1 = comm. object value, bits 15-8
LSB1 = comm. object value, bits 7-0
Integer32
Signed integer – 32 bits
2
MSB1 = comm. object value, bits 31-24
LSB1 = comm. object value, bits 23-16
MSB2 = comm. object value, bits 15-8
LSB2 = comm. object value, bits 7-0
Unsigned32
Unsigned integer – 32 bits
2
MSB1 = comm. object value, bits 31-24
LSB1 = comm. object value, bits 23-16
MSB2 = comm. object value, bits 15-8
LSB2 = comm. object value, bits 7-0
Binary8
Binary number – 8 bits
1
MSB1 = 0
LSB1 = comm. object value
Binary16
Binary number – 16 bits
1
MSB1 = comm. object value, bits 15-8
LSB1 = comm. object value, bits 7-0
Binary32
Binary number – 32 bits
2
MSB1 = comm. object value, bits 31-24
LSB1 = comm. object value, bits 23-16
MSB2 = comm. object value, bits 15-8
LSB2 = comm. object value, bits 7-0
Char
ASCII character
1
MSB1 = 0
LSB1 = comm. object value
List
String list
1
MSB1 = 0
LSB1 = comm. object value
ShortStr
ASCII string of max. length of 15
characters (zero terminated string)
8
MSB1 = 1. character of the string
LSB1 = 2. character of the string
MSB2 = 3. character of the string
LSB2 = 4. character of the string
…
LongStr
ASCII string of max. length of 31
characters (zero terminated string)
16
MSB1 = 1. character of the string
LSB1 = 2. character of the string
MSB2 = 3. character of the string
LSB2 = 4. character of the string
…
Date
Date
2
MSB1 = BCD(day)
LSB1 = BCD(month)
MSB2 = BCD(year)
LSB2 = 0
example:
MSB1 = 18 (HEX)
LSB1 = 04 (HEX)
MSB2 = 01 (HEX)
LSB2 = 0
 Date = 18.4.(20)01
1
MSBx = register x, bits 15-8
LSBx = register x, bits 7-0
