ID-FLX Lite Global Guide
192
Related FW 2.5.0 Related applications
Comm object 304
Description
Input works in MAN mode only switching between running states Nominal/Idle. Active Nominal/Idle input
activates binary output Idle/Nominal and sends Speed request = Idle speed (page 118) and/or active
(binary) IDLE command to the ECU (e.g. to Volvo EMS).
Eng state Sped request in MAN mode Sped request in AUT mode
Idle Idle speed (page 118) Idle speed (page 118)
Running ECU SpeedAdj (page 123)
… anything within
MinSpeedLim (page 124)
MaxSpeedLim (page 124)
Active input opens the READY TO LOAD (PAGE 204) during the engine running state. Ready to Load can be
closed back (if other conditions are fulfilled – see the READY TO LOAD (PAGE 204) description) if
Nominal/Idle is opened.
Nominal/Idle
6 back to List of LBI
Related FW 2.5.0 Related applications
Comm object 165
Description
If the input is active, the Speed Request may increase the engine speed value. The Speed Request value
may also depend on the conditions which are described in the chapter below.
Note: See Speed request chart (page 64).
Speed Up
6 back to List of LBI
Related FW 2.5.0 Related applications
Comm object 164
Description
If the input is active, the Speed Request may decrease the engine speed value. The Speed Request value
may also depend on the conditions which are described in the chapter below.
Note: Speed Up/Down binary inputs are active only when LAI SpdRequest (page 129) = OFF.
Note: See Speed request chart (page 64).
Speed Down
6 back to List of LBI
