Group: Generator settings
Subgroup: Overload Protection
Setpoint group Generator settings Related FW 1.2.1
Range [units] 0 .. 200 [%]
Default value 120 % Alternative config NO
Step
1 % of Nominal Power (page 156)
Comm object 8280 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold level for generator overload (in % of Nominal power) protection. Protection is BOC (Breaker Open
and gen-set Cooldown).
Note: When there is no control of breakers, the type of protection is Sd not BOC.
Overload BOC
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.2.1
Range [units] 0 .. 200 [%]
Default value 120 % Alternative config NO
Step
1 % of Nominal Power (page 156)
Comm object 9685 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold level for generator overload (in % of Nominal power) protection. This is only warning.
Overload Wrn
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.2.1
Range [units] 0,0 .. 600,0 [s]
Default value 5,0 s Alternative config NO
Step 0,1 s
Comm object 8281 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Delay for Overload BOC (page 194)Overload BOC (page 194) protection.
Overload BOC Delay
6 back to List of setpoints
