InteliLite Global Guide
294
Setpoint group Basic settings Related FW 1.2.1
Range [units] 100 .. 4 000 [RPM]
Default value 1 500 RPM Alternative config YES
Step 1 RPM
Comm object 9916 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
When logical binary input CONFIGURATION 2 (PAGE 450) is active, then setpoint Nominal RPM (page 160) has
the same value as setpoint Nominal RPM 2. Setpoint Nominal RPM (page 160) can be changed from both
places - from Basic settings setpoint group and from Alternate Config setpoint group.
Nominal RPM 2
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.2.1
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 12053 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type 2 (page 293).
Description
When logical binary input CONFIGURATION 2 (PAGE 450) is active, then setpoint Nominal Voltage Ph-N (page
158) has the same value as setpoint Nominal Voltage Ph-N 2. Setpoint Nominal Voltage Ph-N (page 158) can
be changed from both places - from Basic settings setpoint group and from Alternate Config setpoint group.
Nominal Voltage Ph-N 2
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.2.1
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 12056 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type 2 (page 293).
Description
When logical binary input CONFIGURATION 2 (PAGE 450) is active, then setpoint Nominal Voltage Ph-Ph (page
159) has the same value as setpoint Nominal Voltage Ph-Ph 2. Setpoint Nominal Voltage Ph-Ph (page 159)
can be changed from both places - from Basic settings setpoint group and from Alternate Config setpoint
group.
Nominal Voltage Ph-Ph 2
6 back to List of setpoints
