ComAp InteliLite MRS16 User Manual

InteliLite Global Guide
158
Three phase voltage measurement L1,L2,L3
3x CT (Current Transformer)
3Ph4Wire Grounded Star (Grounded Wye) connection – 3PY
Three phase voltage measurement L1,L2,L3 with 120° phase shift
3x CT (Current Transformer)
Autodetect
High Leg Delta
or
L1 >=100V; L1 <=140V
L2 >=140V
L3 >=100V; L3 <=140V
3PH3Wire or 3Ph4Wire
or
L1 >=100V
L2 >=100V
L3 >=100V
Split Phase
or
L1 >=100V
L2 <= 20V
L3 >=100V
Mono Phase
or
L1 >=100V
L2 <= 20V
L3 <= 20V
Voltage Autodetect shutdown
Note: To lock this setpoint against editing you also have to lock setpoint Connection Type 1 (page 290)
and Connection type 2 (page 293).
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.2.1
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 8277 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Connection type (page 157).
Description
Nominal system (generator) voltage (phase to neutral).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-N 1 (page
292) and Nominal Voltage Ph-N 2 (page 294).
Nominal Voltage Ph-N
6 back to List of setpoints
